Radium Engineering R14A Fuel Cell Can - 14 Gallon

Radium Engineering 20-0666 fuel tank - 6 gal (23 l).

A lightweight, heavy-duty aluminum can designed for the Radium RA-Series sports fuel bladder with a 6-gallon capacity. Compatible with a wide range of motorsport applications and complies with FIA FT-3 1999 and SFI 28.3 approvals.

Key features

- TIG-welded 5052 aluminum housing: low weight and high corrosion resistance.

- Integrated M8 mounting points for easy frame or cage installation.

- ¼-turn hose cutouts and threaded AN grommets allow quick connection of the power system.

- Pass-through cable channel for electric pump (bulkhead) - no extra holes to drill.

- Removable service cover with Viton® gasket ensures easy access to the bladder and pump.

- Compatible with Radium RA-Series universal bladders (RA-6AB, RA-6AN) or replacement ATL/FT3 bladders of the same format.

External dimensions

Length: 432mm
Width: 432mm
Height: 292mm
