Application: Ecumaster EMU, EMU Black, Ecumaster Keypad, Motec, Pectel ect.The Power Management Unit Ecumaster PMU (Power Management Unit) is a device that completely eliminates the fuse box and relays in the car installation.The module is fully programmable and has a number of strategies such as sequential switching on and off of devices, device restart in case of failure or overvoltage, subsequent shutting down in case of voltage drop in a specific order and LEDs indicating the status of individual outputs.PMU significantly simplifies the car's beam, lowers the weight of the entire installation and protects the car against expensive failures.OUTPUT:
- 10 x 25A
- 6 x 15A
- Dedicated exit for wipers with parking function
INPUT:
COMMUNICATION:
- 2 x CAN - including diagnostics, power consumption, input voltage, errors.
OTHERS:
- Built-in accelerometers with power off function during an accident.
- LEDs indicating the status of outputs.
- 256MB of memory (login speed up to 500hz) (only version with built-in datalogger)
PLUG:
DIMENSIONS:
WEIGHT 345g
