VIAIR 380C Chrom Compressor 380C is a truly-rated continuous duty, 12-volt, 200 PSI compressor.
It is capable of filling a 5.0-gallon tank from 165 PSI to 200 PSI in 3 1/2 minutes consistently, while never pulling more than 23 amps of power (@ 13.8 volts).
Features include a standard 1/4" stainless steel braided leader hose with 1/4" NPT inline check valve and insulated wiring.
Features:
- Check Valve
- Vibration Isolators
- Mounting Hardware
- Stainless Steel Braided Leader Hose
- Air Line for Remote Mount Air Filter
- Remote Mount Air Filter Assembly
- (2) Replacement Air Filter Elements
Specyfications:
- 12-Volt
- Permanent Magnetic Motor
- Duty Cycle: 100% @ 100 PSI (55% @ 200 PSI)
- Max. Working Pressure: 200 PSI
- Max. Air Tank Size: 5.0 Gallon
- Max. Amp Draw: 23 Amps
- Ingress Protection Rating: IP67
- Dimensions: 9"L x 4"W x 6.75"H
- Net Weight: 8.75 lbs.
| 2.5 Gallon Tank | Fill Rate |
| 0 to 145 PSI | 3 min. 30 sec. (± 10 sec.) |
| 110 to 145 PSI | 1 min. 10 sec. (± 05 sec.) |
| 0 to 200 PSI | 6 min. 05 sec. (± 10 sec.) |
| 165 to 200 PSI | 1 min. 40 sec. (± 05 sec.) |
| 5.0 Gallon Tank | Fill Rate |
| 0 to 145 PSI | 7 min. 20 sec. (± 10 sec.) |
| 110 to 145 PSI | 2 min. 25 sec. (± 05 sec.) |
| 0 to 200 PSI | 13 min. 25 sec. (± 15 sec.) |
| 165 to 200 PSI | 3 min. 39 sec. (± 10 sec.) |
